iGuzzini Underscore LED 13W 4000K 1061lm Profile Linear

Description

Description

Code M848
Module version 12 LED 24V high output (12W total) – white, shades neutral white (4200K) – color rendering index (CRI) 80. Power supply not included.
LED 13W, 1061lm
Luminous efficiency (lm / W): 37
4000K CRI80
Dimensions (mm): 1000x26x13, Weight (kg): 00:28

Product-profile drive for linear lighting LED, arranged for surface mounting. High Flux version suitable for lighting display cases, shelves, display corners and outer edges.
Structure in extruded aluminum bar, linear screen in opal polycarbonate diffuser. Side caps and end caps in molded polycarbonate; removing the terminals you can connect directly with later profile thanks to a practical system of quick coupling.

Optics: G – General lighting
Adjustability: Fixed
Group separate electronic
Material: Extruded aluminum
Environment: Indoor IP40
Constant voltage power supplies to be ordered separately

Installation: Fixing snap profile no included clips (MWJ8); the clips are fixed to the installation surface by means of screws and bolts (not included).

Notes
For mounting, connections and power use components available to order separate coding. For systems consistent and relevant lengths it is possible to use electronic ballasts DIN: 9910 (72W) – 9911 (96W) – 9912 (240W)

Manufacturer : IGuzzini check_circle In stock In store we have 3 Items

Data sheet :

Barcode

8025550237722

Reference

3.M848.712.0

Input voltage

24 VOLT DC

Depth in mm

13

Width in mm

26

Length in mm

1000

Degree of protection

IP40

Finish

SILVER

Material

Aluminum

Average hours duration

60000

Adjustable power

Dimmable

Watt power

13 W

Light Temperature

4000 K Neutral White

Product Color

GRAY COLOR

Number of light sources

13

Complete with bulb

Bulb included

Warranty : 2-year warranty from date of purchase counter_2 workspace_premium
